Supported Video Mixers

Tally Hub integrates seamlessly with popular video mixing software to provide real-time tally updates for your production workflow.

🎬 Currently Supported

  • OBS Studio


    Program/Preview Tally with real-time scene change detection

    Recording Status visual indication when recording

    Streaming Status shows live streaming state

    Source Discovery automatic detection of scene sources

    WebSocket API low-latency, reliable communication

  • vMix Professional


    Full Tally Matrix support for all 1000 inputs

    Preview/Program complete preview and program tally

    Recording/Streaming production status indicators

    Input Types all vMix input types supported

    TCP API native vMix protocol communication

⚙️ OBS Studio Setup

Requirements

  • OBS Studio: Version 28.0+ (built-in WebSocket) or 27.x with plugin
  • WebSocket Plugin: obs-websocket for older versions
  • Network Access: OBS and Tally Hub on same network

Configuration Steps

  1. Enable WebSocket in OBS:

    Tools → WebSocket Server Settings
    ✅ Enable WebSocket server
    Port: 4444 (default)
    Password: [optional but recommended]


  2. Configure in Tally Hub:

    {
      "type": "obs",
      "host": "localhost",
      "port": 4444,
      "password": "your-password"
    }


  3. Verify Connection:

  4. Green status indicator in admin panel
  5. Scene list appears in source assignment
  6. Tally lights respond to scene changes

Supported Features

Feature Status Description
Scene Switching ✅ Full Support Instant tally updates on scene changes
Source Preview ✅ Full Support Preview assignments for studio monitor
Recording State ✅ Full Support Red indicator when recording active
Streaming State ✅ Full Support Live indicator during stream
Multiple Scenes ✅ Full Support Support for unlimited scenes
Nested Sources ✅ Full Support Groups and nested scene items

📺 vMix Setup

Requirements

  • vMix: Any current version with TCP API enabled
  • Network Access: vMix and Tally Hub on same network
  • Web Controller: Must be enabled in vMix settings

Configuration Steps

  1. Enable vMix Web Controller:

    Settings → Web Controller
    ✅ Enable Web Controller
    Port: 8088 (default)
    Username: [optional]
    Password: [optional]


  2. Configure in Tally Hub:

    {
      "type": "vmix",
      "host": "localhost",
      "port": 8088,
      "username": "admin",
      "password": "password"
    }


  3. Verify Connection:

  4. vMix inputs appear in source list
  5. Tally responds to preview/program changes
  6. Recording status reflects vMix state

Supported Features

Feature Status Description
Input Switching ✅ Full Support All 1000 vMix inputs supported
Preview Tally ✅ Full Support Preview assignments and switching
Program Tally ✅ Full Support Live program output detection
Recording ✅ Full Support Recording state detection
Streaming ✅ Full Support Live streaming indicators
MultiView ✅ Full Support MultiView source assignments

🔄 Coming Soon

  • ATEM Switchers


    Blackmagic ATEM Support - In Development

    Direct Ethernet protocol integration

    All ATEM switcher models

    Preview/Program tally matrix

    Upstream/Downstream keyer support

    Expected Release: Version 1.1.0

  • Tricaster


    NewTek Tricaster Support - Planned

    LiveSet API integration

    Multi-output tally support

    Virtual input compatibility

    DDR playback integration

    Expected Release: Version 1.2.0

🔌 Custom Integrations

REST API

For mixers not directly supported, use our comprehensive REST API:

# Set tally states manually
curl -X POST http://localhost:3000/api/tally \
  -H "Content-Type: application/json" \
  -d '{"source": "Camera 1", "state": "program"}'

# Get current tally states
curl http://localhost:3000/api/tally/status

WebSocket Events

Real-time integration for custom applications:

const ws = new WebSocket('ws://localhost:3000');

// Listen for tally state changes
ws.on('message', (data) => {
  const update = JSON.parse(data);
  if (update.type === 'tally_update') {
    console.log(`${update.source}: ${update.state}`);
  }
});

// Send tally updates
ws.send(JSON.stringify({
  type: 'set_tally',
  source: 'Camera 1',
  state: 'program'
}));

Plugin Development

Create custom mixer integrations:

import { MixerPlugin } from '@tally-hub/plugins';

export class CustomMixerPlugin extends MixerPlugin {
  async connect(config: MixerConfig): Promise<void> {
    // Implement connection logic
  }

  async getTallySources(): Promise<TallySource[]> {
    // Return available sources
  }

  onTallyChange(callback: (update: TallyUpdate) => void): void {
    // Handle tally state changes
  }
}

⚙️ Configuration Reference

OBS Studio Configuration

mixer:
  type: obs
  host: localhost          # OBS Studio IP address
  port: 4444              # WebSocket port (default: 4444)
  password: ""            # WebSocket password (optional)
  reconnect_interval: 5   # Reconnection attempt interval (seconds)
  timeout: 10             # Connection timeout (seconds)

vMix Configuration

mixer:
  type: vmix
  host: localhost          # vMix IP address
  port: 8088              # Web Controller port (default: 8088)
  username: ""            # Web Controller username (optional)
  password: ""            # Web Controller password (optional)
  poll_interval: 100      # Status polling interval (milliseconds)
  timeout: 5              # Connection timeout (seconds)

Multiple Mixers

Tally Hub can connect to multiple mixers simultaneously:

mixers:
  - name: "Main OBS"
    type: obs
    host: 192.168.1.100
    port: 4444

  - name: "Backup vMix"
    type: vmix
    host: 192.168.1.101
    port: 8088

  - name: "Graphics OBS"
    type: obs
    host: 192.168.1.102
    port: 4445

🔧 Troubleshooting

Common Connection Issues

OBS Studio

  • WebSocket not enabled: Check Tools → WebSocket Server Settings
  • Port conflicts: Try different port if 4444 is in use
  • Firewall blocking: Allow Tally Hub through Windows Firewall
  • Wrong password: Verify WebSocket password matches

vMix

  • Web Controller disabled: Enable in Settings → Web Controller
  • Authentication required: Check username/password requirements
  • Network unreachable: Verify vMix and Tally Hub can communicate
  • Port conflicts: Default port 8088 might be in use

Performance Optimization

Network Settings

  • Wired connection preferred over WiFi for mixers
  • Same subnet for lowest latency
  • Gigabit network for large installations
  • QoS prioritization for real-time traffic

Mixer Settings

  • Reduce polling frequency if CPU usage is high
  • Dedicated network interface for production traffic
  • Minimize concurrent connections to mixer APIs

🚀 Getting Started

  1. Download Tally Hub and install on your system
  2. Configure your video mixer using the guides above
  3. Connect devices using our hardware setup guide
  4. Test the system with web-based tallies first
  5. Scale up with physical tally devices as needed

Need help? Check our troubleshooting guide or join the community for support.
